Home ProductsPower Transmission Poles

Double Circuit Suspension Steel Electrical Transmission Poles Yield Strength 235 Mpa

Double Circuit Suspension Steel Electrical Transmission Poles Yield Strength 235 Mpa

Double Circuit Suspension Steel Electrical Transmission Poles Yield Strength 235 Mpa

Product Details:

Place of Origin: China
Brand Name: JSHG
Certification: ISO/CNAS/IAF/CA
Model Number: HG-SP-110KV

Payment & Shipping Terms:

Minimum Order Quantity: One 40 HQ Container
Price: negotiation
Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time: 2 weeks per container after PO / drawing / prepayment confirmed
Payment Terms: L/C, T/T or Western Union
Supply Ability: 3,000 Metric Tons per Month
Contact Now
Detailed Product Description
Application: Electrical Power Transmission And Distribution Line Wall Thickness: 30mm
Material: Hot Roll Steel Q235, Q345, Q420, Q460, Gr.50, Gr.65, SS400, Etc. Shape: Round / Polygonal / Conical / Tubular / Tapered
Galvanization: Chinese Standard GB/T 13912-2002 And American Standard ASTM A123 Welding: According To AWS D 1.1, CO2 Welding Or Submerged Arc Auto Methods

ISO9001 Yield Strength 235Mpa Double Circuit Suspension Steel Pole



Specifications:



Application

ISO9001 Yield Strength 235Mpa Double Circuit Suspension Steel Pole

Type

Suspension Pole, Tensile Pole, Strain Pole , Angle Pole, Dead-end Pole, etc.

Voltage
Grade

10~500KV (10KV, 13.8KV,33KV, 35KV, 66KV, 110KV,132KV, 220KV,
230KV, 330KV, 500KV or Others )

Shape

Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc),Tubular,
Tapered

Material

Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65, ST-37,
ST-44, ST-52, S355JR, S355J2G3, SS41, SS50, SS55 and others equivalent steel
 material

Once Forming

16m Once forming without joint

Welding

Welding complies with AWS D1.1 standard.
CO2 welding or submerged arc auto methods
No fissure, scar, overlap, layer or other defects
Internal and external welding makes the pole more beautiful in shape
If customers need any other requirements of welding, we also can make
adjustment ad your request

Joint

Joint with insert mode, flange mode.

Wall thickness 2~30mm

Base plate

Base plate is square / round / Polygon with slotted holes for anchor bolt and dimension
 as per client’s requirement.

Galvanization

Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and
American standard ASTM A123.

Life Period

More than 25 years, it is according to installing environment

Advantages

Short Construction Cycle
Less Land Occupation
Low Overall Cost
Easy Installation and Maintenance
Weather Resistance
Anti-corrosion
ODM & OEM are available
Capable to Handle Volume Orders
Provide Professional Design by Our Experienced R&D Engineers


 Description:



Hot Dip Galvanized Electrical Power Steel Tubular Poles plays an important role in electrical power transmission and distribution industry. In order to meet the increasingly higher demand for steel poles, our company design and produce many kinds of steel poles for the power transmission and distribution system. Besides, our electrical steel poles have been tested and approved by the Transmission Pole Tower Testing Station.



The hot dip galvanization technique could protect steel pole from corrosion for as long as 50 years

As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole could be utilize to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.




Quality Control Management



Double Circuit Suspension Steel Electrical Transmission Poles Yield Strength 235 Mpa
JSHG has passed the ISO9001 quality management system. Besides, it processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon
and sulfur microcomputer analyzer etc.
Meanwhile, it has formed a scientific and strict quality management system, which effectively and strictly guarantees the quality control of products form raw material to finished products.

Production Process Flow Chart:



Double Circuit Suspension Steel Electrical Transmission Poles Yield Strength 235 Mpa
Packaging & Shipping:



Double Circuit Suspension Steel Electrical Transmission Poles Yield Strength 235 Mpa
