Burial Type 25FT Power Transmission Poles , Electrical Transmission Poles

Burial Type 25FT Power Transmission Poles , Electrical Transmission Poles

    • Burial Type 25FT Power Transmission Poles , Electrical Transmission Poles
    • Burial Type 25FT Power Transmission Poles , Electrical Transmission Poles
  • Burial Type 25FT Power Transmission Poles , Electrical Transmission Poles

    Product Details:

    Place of Origin: China
    Brand Name: JSHG
    Certification: ISO/CNAS/IAF/CA
    Model Number: HG-SP-110KV

    Payment & Shipping Terms:

    Minimum Order Quantity: One 40 HQ Container
    Price: negotiation
    Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Delivery Time: 2 weeks per container after PO / drawing / prepayment confirmed
    Payment Terms: L/C, T/T or Western Union
    Supply Ability: 3,000 Metric Tons per Month
    Contact Now
    Detailed Product Description
    Height: 25ft Shape: 8 Sides
    Material: Q345 Design Load: 300kg
    Appearance Treatment: Hot-dip Galvanized Wall Thickness: 2.5mm
    High Light:

    transmission line pole

    ,

    electrical transmission poles





    Burial Type 25FT NEA Standard Power Transmission Poles for Philippines Market



    Product Description:



    Products

    • Burial Type 25FT NEA Standard Power Transmission Poles for Philippines Market

    Application

    • Electrical Power transmission and distribution line

    Standrad

    • Philippines NEA Standard

    Shape

    • 8 sides , conical

    Material

    • Applied to the material of general-purpose steel GB/T1591-2008, Q345 used in China.

      Q345 equipment to ASTM GR50. Min Yield Stress 345 Mpa.



    Wall thickness

    • 3.0 mm

    Type

    • Direct Buried

    Delivery Time

    • 2 weeks per container after PO/drawing/prepayment confirmed

    Life Period

    • More than 25 years, it is according to installing environment

    Packaging Details

    • Covered by Plastic Wrap or Mat or according to client's requests.

    • The Loading Pcs of Each Container could be calculated according to client's specification and data.

    Export Foreign Country

    • America ,Morocco,Sir Lanka ,Russia, Jordan,Guyana,Nigeria, Australia, Spain, Indonesia, Singapore, the Philippines, Kenya,etc



    Burial Type 25FT Power Transmission Poles , Electrical Transmission Poles 0



    Product Detial:





    National Electrification Administration (Philippines)
    Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT



    Height(ft)

    Thickness(mm)

    Butt Diameter(mm)

    Top Diameter(mm)

    Design Load(kg)

    Yield Stress(MPA)

    Zinc Coating(microns)

    25

    2.5

    152

    120

    300

    345

    86

    30

    3.0

    226

    127

    500

    345

    86

    35

    3.0

    248

    127

    500

    345

    86

    40

    3.0

    317

    127

    500

    345

    86







    1.Top diameter:120mm

    2.Bottom diameter:152mm

    3.Thickness:2.5mm

    4.Material:yield strength not less than 345mpa(GB/T1591-2008standard)

    5.Management team :  ISO management ,We are award ISO 9001:2008 certificate . .
    QC inspection :It is our company policy that all the finish product should be inspected by our specialized QC in every manufacture steps and before every shipment

    6.Welding :complies with AWS D1.1 standard.CO2 welding or submerged arc auto methods.No fissure, scar, overlap, layer or other defects

                       Internal and external welding makes the pole more beautiful in shape

    7.Design load: 300kg



    We always insist on one-on-one service to our client since our first contact with our clinet to save our client's time and no need to spend their time to rebuild the trust and relationship with new service personal.Because of the time difference between us and our client, we do our best to provide 7*24 service to let our clients can contact with us as solve their questions ASAP. The minimum standard we promise you that all your questions can be received our reply within 24 hours.



    Production Procession Line Chat:

    Raw material test → Cutting →Molding or bending →Weldng (longitudinal )→Dimension verify→Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting→Recalibration →Thread →Packages



    Burial Type 25FT Power Transmission Poles , Electrical Transmission Poles 1







    Packaging&Shipping:



    Our poles as normal are covered by Mat or straw bale at the top and bottom and woods between the poles can avoid the damage of the galvanization on the surface of steel poles, anyway also we can follow clients required.



    Our Service



    • Reply within 24 Working Hours
    • Factory Direct Sale
    • High-Quality and Low-Price Product
    • Provide Professional Design by Our Experienced R&D Engineers
    • Rich Exporting Experience
    • Technical Support by E-mail
    • Calling service
    • Capable to Handle Volume Orders
    • More than 15 Years Design & Manufacture Experience
