ISO Hot Dip Galvanized Power Transmission Poles With PLS Design 13.8KV Q355

ISO Hot Dip Galvanized Power Transmission Poles With PLS Design 13.8KV Q355

    • ISO Hot Dip Galvanized Power Transmission Poles With PLS Design 13.8KV Q355
    • ISO Hot Dip Galvanized Power Transmission Poles With PLS Design 13.8KV Q355
  • ISO Hot Dip Galvanized Power Transmission Poles With PLS Design 13.8KV Q355

    Product Details:

    Place of Origin: China
    Brand Name: JSHG
    Certification: ISO/CNAS/IAF/CA
    Model Number: HG-SP-110KV

    Payment & Shipping Terms:

    Minimum Order Quantity: One 40 HQ Container
    Price: negotiation
    Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Delivery Time: 2 weeks per container after PO / drawing / prepayment confirmed
    Payment Terms: L/C, T/T or Western Union
    Supply Ability: 3,000 Metric Tons per Month
    Contact Now
    Detailed Product Description
    Height: 14m Standard: ISO9001
    Material: Q345, Q235 Voltage: 13.8KV
    Appearance Treatment: Hot-dip Galvanized Welding: CO2 Welding Or Submerged Arc Auto Methods
    High Light:

    electrical power poles

    ,

    electrical transmission poles



    Hot Dip Galvanized Power Transmission Poles with PLS Design 13.8KV Q355




    Product Description:




    Products

    • Hot Dip Galvanized Power Transmission Poles with PLS Design 13.8KV Q355

    Brackets



    • Single or double brackets are in the shape and dimension as per customers requirement

    Shape of pole

    • Round,conical,polygonal shafts are made of steel sheet that folded into required shape and welded longitudinally by automatic arc welding machine

    Material

    • Q345B/A572,minimum yield strength>=345n/mm2
      Q235B/A36,minimum yield strength>=235n/mm2

    • As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50

    Base plate

    • Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement

    Identification

    • Name plate

    Welding

    • AWS D1.1 standard.

    • CO2 welding or submerged arc auto methods

    • No fissure, scar, overlap, layer or other defects
    • Internal and external welding makes the pole more beautiful in shape
    • If customers need any other requirements of welding, we also can make adjustment ad your request



    Galvanization

    • Hot dip galvanization with thickness of 80-100µm average

    Life Period

    • More than 25 years, it is according to installing environment

    Package

    • Plastic Wrap or Mat or according to client's requests

    Appearance
    • Bitumen painted




    The power transmission pole of our company are made from quality sheets through bending,forming, automatic welding, hot dip galvanization. We owned advanced production-line, including flatting machine, steel plate shearer, bending machine,auto-closed up machine, submerged arc welding machine and powder coating line, and our workmanship and quality control was achieved high opinion from our clients.



    Product Export Experiences:


    Philippines , Malaysia , Pakistan , Russia , UK , Australia , Ghana , Angola , Tanzania , Slovakia , New Zealand , Sierra Leone , Bangladesh , Maxico , Nigeria , Republic of the Congo , etc,


    ISO Hot Dip Galvanized Power Transmission Poles With PLS Design 13.8KV Q355 0




    Manufacturing:


    Raw material: Q235 or Q345 in China. We get the raw material checked in our lab test room. Silicon less than2%. We have carbon and sulfur analyzer to check the elements of the steel sheet. We'll return the steel if they are unqualified. So in this way, we can control the quality of the steel poles from the first beginning.

    Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All insure us to produce steel poles with the best quality.

    After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.





    Company Information:


    JIANGSU HONGGUANG STEEL POLE CO., LTD.
    With over 15 Years of Experience/ Capable to Handle Volume Orders
    Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.
    Founded in 1998, Jiangsu Hongguang Steel Pole Co. Ltd (JSHG) specializes in manufacturing various structures. We manufacture a variety of products like structure and Substation Structure for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telcommunication poles for the telecommunication industry; Traffic Poles & Camera Poles & Sign Structures for transportation Industry and Advertising Industry.

    ISO Hot Dip Galvanized Power Transmission Poles With PLS Design 13.8KV Q355 1
