69KV Hot Dip Galvanized Steel Tubular Pole

69KV Hot Dip Galvanized Steel Tubular Pole

  • 69KV  Hot Dip Galvanized Steel Tubular Pole
  • 69KV  Hot Dip Galvanized Steel Tubular Pole
  • 69KV  Hot Dip Galvanized Steel Tubular Pole
69KV  Hot Dip Galvanized Steel Tubular Pole
Product Details:
Place of Origin: China
Brand Name: JSHG
Certification: ISO/CNAS/IAF/CA
Model Number: HG-SP
Payment & Shipping Terms:
Minimum Order Quantity: One 40 HQ Container
Price: negotiation
Delivery Time: 1 week
Payment Terms: L/C, T/T or Western Union
Supply Ability: 3,000 Metric Tons per Month
Contact Now
Detailed Product Description
Voltage Grade: 69KV Application: Power Transmission And Distribution Line
Shape: Conical, Polygonal, Etc. Export Country: Philippines
Certificates: ISO9001-2008 , AAA Credit Rating, Etc Joint Of Poles: Insert Mode,innerflange Mode,face To Face Joint Mode
High Light:

69KV Steel Tubular Pole


transmission Steel Tubular Pole


69KV galvanized Steel Pole

69KV hot dip galvanized steel electric power pole for transmission line

Product Description:

Our compnay could design the practical steel electrical power poles for customers' special use, normally we need customers to provide us some parameter, like as the followings :

- Pole top design load
- Where is the position of the load, the distance from the top
- The wind Speed
- How will the wire distribute
- Pole type with Burial Type or Base Plate type
- The connections mode, use slip joint or flange
- and others can be furthermore discussed when needed.

Raw Material
Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345, Q420, Q460 used in China.












Grade D






















Product Specification:



  • Q345 Material 30FT 3mm Thick Hot Dip Galvanized Steel Tubular Pole

Voltage Grade

  • 13.8KV


  • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.


  • According to AWS D 1.1, CO2 welding or submerged arc auto methods

  • No fissure, scar, overlap, layer or other defects

  • If customers need any other requirements of welding, we also can make adjustment ad your request

Life Period

  • More than 25 years, it is according to installing environment

Surface treatment

  • Hot dip galvanized Following ASTM A 123,
    color polyester power or any other standard by client required



  • Weather Resistance

  • Anti-corrosion

  • ODM & OEM are available

  • Capable to Handle Volume Orders

  • Provide Professional Design by Our Experienced R&D Engineers


Product Test:


JSHG has passed the ISO9001 quality management system. Besides, it processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.




69KV  Hot Dip Galvanized Steel Tubular Pole 0


69KV  Hot Dip Galvanized Steel Tubular Pole 1



NEA Standard Specification:


Octagonal Galvanized Steel Pole 25FT, 30FT, 35FT, 40FT,45FT






Butt Diameter


Tip Diameter


Design Load


Yield Stress


Zinc Coating


25 2.5 152 120 300 345 86
30 3.0 226 127 500 345 86
35 3.0 248 127 500 345 86
40 3.0 317 127 500 345 86
45 3.0 328 127 500 345 86



Production Process:

  • Raw material test
  • Cutting
  • Bending
  • Welding (longitudinal )
  • Dimension verify
  • Flange welding
  • Hole drilling
  • Calibration
  • Galvanization or powder coating or Bituminous painting
  • Recalibration
  • Packages
