Q460 Multi Side 3.5mm Swaged Steel Tubular Pole for Power transmission
  • Q460 Multi Side 3.5mm Swaged Steel Tubular Pole for  Power transmission

Q460 Multi Side 3.5mm Swaged Steel Tubular Pole for Power transmission

Place of Origin China
Brand Name JSHG
Certification ISO/CNAS/IAF/CA
Model Number HG-SP-003
Product Details
Application:
Electrical Power Transmission And Distribution Line
Voltage Grade:
10KV-500KV
Material:
Hot Roll Steel Q235, Q345, Q420, Q460, Gr.50, Gr.65, SS400, Etc.
Shape:
Round / Polygonal / Conical / Tubular / Tapered
Appearance Treatment:
Hot-dip Galvanized / Painting
Connection Structure:
Overlap / Flange Connection
Welding:
According To AWS D 1.1, CO2 Welding Or Submerged Arc Auto Methods
High Light:

3.5mm swaged steel tubular pole

,

Multi Side swaged steel tubular pole

,

Q460 steel tubular pole

Payment & Shipping Terms
Minimum Order Quantity
One 40 HQ Container
Price
negotiation
Delivery Time
1 week
Payment Terms
L/C, T/T or Western Union
Supply Ability
3,000 Metric Tons per Month
Product Description

Oem / Odm Multi Side Steel Tubular Pole 3.5mm Thickness Galvanised Steel Pole

Specifications:

Application

Electrical Power transmission and distribution line
Telecommunication system
Traffic System
Outdoor Lighting Project
Wind Power Project

Shape

Conical, Round, Polygonal ( Octagonal , Dodecagonal , Hexadecagonal , etc), Tubular,
Tapered

Material

Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65, ST-37, ST-44,
ST-52, S355JR, S355J2G3, SS41, SS50, SS55 and others equivalent steel material

Wall thickness

2~30mm

Once Forming

16m Once forming without joint

Welding

Welding complies with AWS D1.1 standard.
CO2 welding or submerged arc auto methods
No fissure, scar, overlap, layer or other defects
Internal and external welding makes the pole more beautiful in shape
If customers need any other requirements of welding, we also can make adjustment ad
your request

Joint

Joint with insert mode, flange mode.

Base plate

Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as
per client’s requirement.

Galvanization

Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and
American standard ASTM A123.

Painting

According to clients' request

Life Period

More than 25 years, it is according to installing environment

Advantages

Short Construction Cycle
Less Land Occupation
Low Overall Cost
Easy Installation and Maintenance
Weather Resistance
Anti-corrosion
ODM & OEM are available
Capable to Handle Volume Orders
Provide Professional Design by Our Experienced R&D Engineers


 Q460 Multi Side 3.5mm Swaged Steel Tubular Pole for  Power transmission 0

Description:
Hot Dip Galvanized Electrical Power Steel Tubular Poles plays an important role in electrical power transmission and distribution industry. In order to meet the increasingly higher demand for steel poles, our company design and produce many kinds of steel poles for the power transmission and distribution system. Besides, our electrical steel poles have been tested and approved by the Transmission Pole Tower Testing Station.
Our steel poles, being manufactured from steel sheet that has been subjected to hydraulic pression and longitudinal welding, has a tapered tubular structure with a multilateral cross section. To achieve a proper height, steel poles can be assembled by insert mode or flange mode at the installation site.
The hot dip galvanization technique could protect steel pole from corrosion for as long as 50 years
As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole could be utilize to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.


Engineering and Design Management

Q460 Multi Side 3.5mm Swaged Steel Tubular Pole for  Power transmission 1


Disign Software
“Design and technology,professional and common, software and hardware” is JSHG‘s design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.
In the R&D Department, there are many experienced senior research & design staff and rigid development network, which ensure our design proposals meet customer demand, even exceed their expectations.

Since the establishment, JSHG have put forward thousands of conical pole design proposals covering several industries and fields, such as power transmission industry, telecommunication industry, lighting industry, etc, which provides complete and strong technical support and service assurance.

Production Process Flow Chart
Q460 Multi Side 3.5mm Swaged Steel Tubular Pole for  Power transmission 2



Terms and Conditions
1.  Price Term: EXW, FOB, CFR or CIF.

  • The price includes pole shaft, base plate, cross arm and anchor bolt.
  • Shipping seaport: Shanghai Seaport.
  • Please provide drawings if you have so that we can calculate the accurate price for you.
  • We also provide design according to your requests, if you don't have drawings.

 2.  MOQ: One 40FT Container.
 3.  Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.
 4.  Delivery Time:  2 weeks per container after PO/drawing/prepayment confirmed.
 5.  Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients’ requirement.



Our Services

  • Reply within 24 Working Hours
  • Factory Direct Sale
  • More than 15 Years Design & Manufacture Experience
  • Capable to Handle Volume Orders
  • High-Quality and Low-Price Products
  • Provide Professional Design by Our Experienced R&D Engineers
  • Rich Exporting Experience
  • ODM, OEM Acceptable
  • Technical Support by E-mail
  • Calling service


Company Profile
JIANGSU HONGGUANG STEEL POLE CO., LTD.
With over 15 Years of Experience/ Capable to Handle Volume Orders
Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.
Founded in 1998, Jiangsu Hongguang Steel Pole Co. Ltd (JSHG) specializes in manufacturing various steel structures. We manufacture a variety of products like Electrical Poles and Substation Structures for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telecommunication Monopole Towers for the telecommunication industry; Traffic Poles & Camera Poles & Advertising Structures for transportation Industry and Advertising Industry.
