CNAS IAF Overlap Connect 13.8KV 30ft Metal Transmission Steel Pole

CNAS IAF Overlap Connect 13.8KV 30ft Metal Transmission Steel Pole

  • CNAS IAF Overlap Connect 13.8KV 30ft Metal Transmission Steel Pole
CNAS IAF Overlap Connect 13.8KV 30ft Metal Transmission Steel Pole
Product Details:
Place of Origin: China
Brand Name: JSHG
Certification: ISO/CNAS/IAF/CA
Model Number: HG-SP-110KV
Payment & Shipping Terms:
Minimum Order Quantity: One 40 HQ Container
Price: negotiation
Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time: 2 weeks per container after PO / drawing / prepayment confirmed
Payment Terms: L/C, T/T or Western Union
Supply Ability: 3,000 Metric Tons per Month
Contact Now
Detailed Product Description
Material: Hot Roll Steel Q235, Q345, A36, Gr50 Etc. Appearance Treatment: Hot-dip Galvanized/painting
Voltage Grade: 13.8KV 69KV Connection Structure: Overlap
Application: Power Transmission And Distribution Line Steel Pole Height Options: 30ft
Keyword: Steel Electric Pole
High Light:

30ft steel power pole

,

13.8KV transmission Steel Pole

,

IAF transmission Steel Pole

13.8KV 30ft Metal Power Poles For Electrical Power Distribution Equipment​



The power pole of our company are made from quality sheets through bending,forming, automatic welding, hot dip galvanization and powder coating. We owned advanced production-line, it included Flatting machine, Steel plate shearer, bending machine,Auto-closed up machine, submerged arc welding machine and powder coating line, and our workmanship and quality control was achieved high opinion from our clients.



Specifications:

item Dimension of (mm) Thickness(mm) The quantity per 40hq can load Material
25ft(in 1 section) 117*152 3 250 ASTM A GR50
30ft(in 1 section) 127*226 3 150 ASTM A GR50
35ft(in 1 section) 127*228 4 140 ASTM A GR50
40ft(in 2 section) 127*317 4 97 ASTM A GR50
50ft(in 2 section) 127*345.1 4.2 45 ASTM A GR65
55ft(in 2 section) 127*357.7 4.2 45 ASTM A GR65
60ft(in 2 section) 127*390.4 4.2 32 ASTM A GR65
65ft(in 2 section) 127*415 4.2 28 ASTM A GR65
70ft(in 2 section) 160*448 5 25 ASTM A GR65
80ft(in 3 section) 254*457 4.11 14 ASTM A GR65



Products

Electrical Power Transimmission Line Steel Tubular Poles/Towers

Type

Suspension Pole,Tensile Pole, Strain Pole , Angle Pole, Dead-end Pole, etc

Voltage Grade

10~500KV (10KV, 13.8KV,33KV, 35KV, 66KV, 110KV,132KV, 220KV, 230KV, 330KV, 500KV or Others )

Shape

Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc)

Material

Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65, ST-37, ST-44, ST-52, S355JR, S355J2G3, SS41, SS50, SS55 and others equivalent steel material

Wall thickness

2~30mm

Once Forming

16m Once forming without joint

Welding

Welding complies with AWS D1.1 standard.

CO2 welding or submerged arc auto methods

No fissure, scar, overlap, layer or other defects

Internal and external welding makes the pole more beautiful in shape

If customers need any other requirements of welding, we also can make adjustment ad your request

Joint

Joint with insert mode, flange mode.

Base plate

Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.

Galvanization

Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.

Painting

According to clients' request

Life Period

More than 25 years, it is according to installing environment

Certificates

ISO9001-2008 , AAA credit rating, etc





We produce any dimensions and thicknesses straight round, tapered round, straight square, tapered square etc pole as your demand.

1) The main body pole adopts the technology of the disposable shaping

2) The welding seam is level and smooth
3) The welding of the lightpost is the automatic Asian arc welding
4) The antiseptic disposing of the lamp pole is the hot galvanizing and the surface is smooth and beautiful
5) Both the adjustment of the color and that of the height are alternative.



CNAS IAF Overlap Connect 13.8KV 30ft Metal Transmission Steel Pole 0



Engineering and Design Management:

“Design and technology,professional and common, software and hardware” is JSHG‘s electric post design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.
