ISO 9001 Standard Steel Power Pole Sheet Metal Fabrication Electrical Poles

ISO 9001 Standard Steel Power Pole Sheet Metal Fabrication Electrical Poles

  • ISO 9001 Standard Steel Power Pole Sheet Metal Fabrication Electrical Poles
  • ISO 9001 Standard Steel Power Pole Sheet Metal Fabrication Electrical Poles
ISO 9001 Standard Steel Power Pole Sheet Metal Fabrication Electrical Poles
Product Details:
Place of Origin: China
Brand Name: JSHG
Certification: ISO/CNAS/IAF/CA
Model Number: HG-SP
Payment & Shipping Terms:
Minimum Order Quantity: One 40 HQ Container
Price: negotiation
Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed
Payment Terms: L/C, T/T or Western Union
Supply Ability: 3,000 Metric Tons per Month
Contact Now
Detailed Product Description
Painting: According To Clients' Request Voltage Grade: 69-220KV
Appearance Treatment: Hot-dip Galvanized Connection Structure: Overlap/flange Connection
Joint: Joint With Insert Mode Welding: According To AWS D 1.1, CO2 Welding Or Submerged Arc Auto Methods
Application: Electrical Power Transformer Substation Thickness: 3.0mm, 3.5mm, 4.0mm
High Light:

electric line pole

,

metal electric pole

ISO 9001 Standard Steel Electric Pole Steel Power Pole Sheet Metal Fabrication Electrical Poles

Product Description:

Our steel pole, steel poles , steel power poles , power distribution equipment , electric power transimission &distribution steel poles ,hot-dip-galvanized steel poles ,lamp poles ,street lamp poles ,solar street lamps steel poles ,high mast lamp poles,road lamp poles, the steel street lamp poles, hot-dip-galvanized steel lighting ,outdoor lighting ,outdoor lamps ,street lighting poles ,steel post ,street poles, lamp parts ,lighting fixture ,lighting poles ,lighting equipment ,lighting decoration ,lighting product , street lighting body, high mast lighting steel poles &tower,electric poles, round&square street lighting steel poles with double arm or single arm . Stainless steel poles, Flag mast stainless steel pole, aluminum street light poles, traffic lighting steel poles, telecom tower poles are made by hot-roll steel coil ,the process as cut plate, bending ,forming,automatic welding,drill holes ,quality check before galvanized, hot dip galvanized or powder coating , final quality check according by client required.

ISO 9001 Standard Steel Power Pole Sheet Metal Fabrication Electrical Poles 0

Product Specification:

Products
  • ISO 9001 Standard Steel Electric Pole Steel Power Pole Sheet Metal Fabrication Electrical Poles
Application
  • Electrical Power Transformer Substation
Voltage Grade
  • 69KV-220KV
Once Forming
  • 16m Once forming without joint
Thickness
  • 3.0mm, 3.5mm, 4.0mm
Welding
  • According to AWS D 1.1, CO2 welding or submerged arc auto methods
Material
  • Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65, ST-37, ST-44, ST-52, S355JR, S355J2G3, SS41, SS50, SS55 and others equivalent steel material

Galvanization

  • Hot dip galvanization of substation structure is in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.

Product Advantages:

1. Short Construction Cycle
2. Low Overall Cost
3. Easy Installation and Maintenance
4. Weather Resistance
5. Anti-corrosion
6. More than 15 Years Design & Manufacture Experience
7. Capable to Handle Volume Orders
8. Provide Professional Design by Our Experienced R&D Engineers
9. Rich Exporting Experience
10. ODM, OEM Acceptable
11. Technical Support by E-mail

Application Scope:

As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel tubular pole could be utilize to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.



Steel tube tower mainly use between high voltage transmission lines, with lightning rod hanging place on top, bolt connecting tower body with cross arm which has wires hanging place. The intersecting surface of tower is oblong, and the intersection surface macroaxis of tower and cross arm is 0 to 90 degree angle. In practical application, raw material can be saved of shorten the circumference of intersection surface by bearing the max bending moment of oblong intersection surface macroaxis.

  ISO 9001 Standard Steel Power Pole Sheet Metal Fabrication Electrical Poles 1

Packaging&Shipping:

* Covered by Plastic Wrap or Mat or according to client's requests.

* The Loading Pcs of Each Container could be calculated according to client's specification and data.

Our poles as normal are covered by Mat or straw bale at the top and bottom and woods between the poles can avoid the damage of the galvanization on the surface of steel poles, anyway also we can follow clients required , The loading capacity of 20GP 40HC or OT/FR will be calculated basing on the clients’ actual specification and data.

Manufacturing:

Raw material: Q235 or Q345 in China. We get the raw material checked in our lab test room. Silicon less than2%. We have carbon and sulfur analyzer to check the elements of the steel sheet. We'll return the steel if they are unqualified. So in this way, we can control the quality of the steel poles from the first beginning.



Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All insure us to produce steel poles with the best quality.
