Steel Tubular Hot Dip Galvanized Pole Power Transmission Pole Joint Connection

Steel Tubular Hot Dip Galvanized Pole Power Transmission Pole Joint Connection

    • Steel Tubular Hot Dip Galvanized Pole Power Transmission Pole Joint Connection
    • Steel Tubular Hot Dip Galvanized Pole Power Transmission Pole Joint Connection
  • Steel Tubular Hot Dip Galvanized Pole Power Transmission Pole Joint Connection

    Product Details:

    Place of Origin: China
    Brand Name: JSHG
    Certification: ISO/CNAS/IAF/CA
    Model Number: HG-SP

    Payment & Shipping Terms:

    Minimum Order Quantity: One 40 HQ Container
    Price: negotiation
    Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed
    Payment Terms: L/C, T/T or Western Union
    Supply Ability: 3,000 Metric Tons per Month
    Contact Now
    Detailed Product Description
    Voltage Grade: 10KV ~ 500KV Welding: Welding Complies With CSA And AWS, AWS D1.1 Standard.
    Zinc Coating: ≥ 86 μm Finishing: Hot Dip Galvanized
    Tolerance: +-2% Min Yield Stress: 345Mpa
    Joint Of Poles: Insert Mode,innerflange Mode,face To Face Joint Mode Coating: Zinc Coating



    Hot Dip Galvanized Steel Tubular Pole Power Transmission Pole Joint Connection



    Product Description:

    1) Steel materials conform to ASTM A36 with Q235(S235,SS400),Q345(S355JR), Q460,etc

    2) Welding: Welding complies with CSA and AWS, AWS D1.1 standard.

    3) Finish: Hot-dip galvanized in accordance with ASTM A123. Min Zinc Coating 86 microns.

    4) Pole Height: Transmission pole ≥ 15M

    5) Pole shape: Conical, Round, Polygonal---Octagonal, Dodecagonal, Hexadecagonal, etc

    6) Type: Straight Pole ,Tensile Pole ,Turn Pole (Double-loop corner pole, Single or double loops/circuit pole, single or double tensile/terminal/straight pole, etc)

    7) Surface hot-dip-galvanized and sometimes with Bituminous Painting as customer's request.

    8) Resistant: against earthquake of 8.8 grade. Wind speed as design.

    9) Quality Standard: ISO9001:2000,AAA credit rating

    10) Easy install and maintenance



    11) Packages: Normally covered by sack or as customer’s requirement.



    12) Voltage:10-550KV



    Product Specification:

    Products
    • Hot Dip Galvanized Steel Tubular Pole Power Transmission Pole Joint Connection
    Application
    • Power Transmission And Distribution
    Voltage Grade
    • 10~500KV (10KV, 13.8KV,33KV, 35KV, 66KV, 110KV,132KV, 220KV, 230KV, 330KV, 500KV or Others )
    Height
    • 10M-50M
    Quality Standard
    • ISO9001:2000,AAA credit rating
    Shape
    • Conical, Round, Polygonal.
    Material
    • Hot Roll Steel Sheet Q345, GR50 which equivalent to S355JR.
    • Min Yield Stree 345 Mpa
    • Tensile Strength 470 Mpa ~ 630 Mpa
    Wall thickness
    • 5-10mm
    Galvanization
    • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123.
    Once Forming
    • 14m Once forming without joint
    • 40GP, 40HQ container Length is 12m , so the poles will be or more than 2 segments if longer than 12m.



    Product Advantages:

    The Hot Dip Galvanized Electrical Power Steel Tubular Pole plays an important role in electrical power transmission and distribution industry. In order to meet the increasingly higher demand for steel tubular pole, our company design and produce many kinds of steel tubular pole for the power transmission and distribution system. Besides, our electrical steel tubular pole have been tested and approved by the Transmission Pole Tower Testing Station.



    Application Scope:

    As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel tubular pole could be utilize to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.
    Steel Tubular Hot Dip Galvanized Pole Power Transmission Pole Joint Connection



    Packaging&Shipping:

    * Covered by Plastic Wrap or Mat or according to client's requests.
    * The Loading Pcs of Each Container could be calculated according to client's specification and data.



    Company Information:

    Steel Tubular Hot Dip Galvanized Pole Power Transmission Pole Joint Connection

    JIANGSU HONGGUANG STEEL POLE CO., LTD.
    With over 15 Years of Experience/ Capable to Handle Volume Orders
    Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.
    Founded in 1998, Jiangsu Hongguang Steel Pole Co. Ltd (JSHG) specializes in manufacturing various structures. We manufacture a variety of products like structure and Substation Structure for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telcommunication poles for the telecommunication industry; Traffic Poles & Camera Poles & Sign Structures for transportation Industry and Advertising Industry.

    “Design and technology,professional and common, software and hardware” is JSHG‘s substation structure design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.
