Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate

    • Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate
    • Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate
    • Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate
  • Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate

    Product Details:

    Place of Origin: China
    Brand Name: JSHG
    Certification: ISO/CNAS/IAF/CA
    Model Number: HG-SP

    Payment & Shipping Terms:

    Minimum Order Quantity: One 40 HQ Container
    Price: negotiation
    Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed
    Payment Terms: L/C, T/T or Western Union
    Supply Ability: 3,000 Metric Tons per Month
    Contact Now
    Detailed Product Description
    Voltage Grade: 10KV ~ 500KV Welding: Welding Complies With CSA And AWS, AWS D1.1 Standard.
    Material: Q235(S235,SS400),Q345(S355JR), Q460,etc Connection Structure: Overlap/Flange Connection
    Shape: Conical, Round, Polygonal---Octagonal, Dodecagonal, Hexadecagonal, Etc Resistant: Against Earthquake Of 8.8 Grade. Wind Speed As Design.
    Quality Standard: ISO9001:2000,AAA Credit Rating Packages: Normally Covered By Sack Or As Customer’s Requirement.



    Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate

    Product Description:

    The Suspension Pole, Strain Pole, Angle Pole in Hot Dip Galvanized in Hot Dip Galvanization was designed as customer's request. For Distribution and Transmission Line use. And with Base Plate use Anchor Bolts to Install. Sections with 2 and use flange to connect each segment. The hot dip galvanized in accordance with ASTM 123 and the zinc coating at least 86 microns.

    The Steel Tubular Poles price is based on its specification, like say different design with different price, normally depend on pole diameter, material, thickness, qty, etc

    Product Specification:

    Products
    • Q345 Steel Tubular Pole Power Transmission Pole with Base Plate
    Application
    • Power Transformation
    Voltage Grade
    • 10~500KV (10KV, 13.8KV,33KV, 35KV, 66KV, 110KV,132KV, 220KV, 230KV, 330KV, 500KV or Others )
    Packages
    • Normally covered by sack or as customer’s requirement.
    Quality Standard
    • ISO9001:2000,AAA credit rating
    Wall thickness
    • 6mm
    Welding
    • According to AWS D 1.1, CO2 welding or submerged arc auto methods
    Pole Height
    •  ≥ 15M
    Type
    • Straight Pole ,Tensile Pole ,Turn Pole (Double-loop corner pole, Single or double loops/circuit pole,
      single or double tensile/terminal/straight pole, etc)
    Finish
    • Hot-dip galvanized in accordance with ASTM A123. Min Zinc Coating 86 microns.



    Product Advantages:

    The Hot Dip Galvanized Electrical Power Steel Tubular Pole plays an important role in electrical power transmission and distribution industry. In order to meet the increasingly higher demand for steel tubular pole, our company design and produce many kinds of steel tubular pole for the power transmission and distribution system. Besides, our electrical steel tubular pole have been tested and approved by the Transmission Pole Tower Testing Station.

    1).Short Construction Cycle
    2).Low Overall Cost
    3).Easy Installation and Maintenance
    4).Weather Resistance
    5).Anti-corrosion
    6).More than 15 Years Design & Manufacture Experience
    7).Capable to Handle Volume Orders
    8).Provide Professional Design by Our Experienced R&D Engineers
    9).Rich Exporting Experience
    10).ODM, OEM Acceptable
    11).Technical Support by E-mail



    Application Scope:

    The Suspension Pole, Strain Pole, Angle Pole in Hot Dip Galvanized in Hot Dip Galvanization was designed as customer's request. For Distribution and Transmission Line use. And with Base Plate use Anchor Bolts to Install. Sections with 2 and use flange to connect each segment. The hot dip galvanized in accordance with ASTM 123 and the zinc coating at least 86 microns.


    Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate



    Packaging&Shipping:

    * Covered by Plastic Wrap or Mat or according to client's requests.
    * The Loading Pcs of Each Container could be calculated according to client's specification and data.

    Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate



    Company Information:

    Electrical Q345 Steel Tubular Pole Power Transmission Pole With Base Plate

    JIANGSU HONGGUANG STEEL POLE CO., LTD.
    With over 15 Years of Experience/ Capable to Handle Volume Orders
    Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.
    Founded in 1998, Jiangsu Hongguang Steel Pole Co. Ltd (JSHG) specializes in manufacturing various structures. We manufacture a variety of products like structure and Substation Structure for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telcommunication poles for the telecommunication industry; Traffic Poles & Camera Poles & Sign Structures for transportation Industry and Advertising Industry.

    “Design and technology,professional and common, software and hardware” is JSHG‘s substation structure design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.



    Production Process:

    • Raw material test
    • Cutting
    • Bending
    • Welding (longitudinal )
    • Dimension verify
    • Flange welding
    • Hole drilling
    • Calibration
    • Galvanization or powder coating or Bituminous painting
    • Recalibration
    • Packages
