15M Hot Dip Galvanized Steel Transmission Pole Q345 Two Segments Overlap Type

15M Hot Dip Galvanized Steel Transmission Pole Q345 Two Segments Overlap Type

    • 15M Hot Dip Galvanized Steel Transmission Pole Q345 Two Segments Overlap Type
    • 15M Hot Dip Galvanized Steel Transmission Pole Q345 Two Segments Overlap Type
  • 15M Hot Dip Galvanized Steel Transmission Pole Q345 Two Segments Overlap Type

    Product Details:

    Place of Origin: China
    Brand Name: JSHG
    Certification: ISO/CNAS/IAF/CA
    Model Number: HG-SP

    Payment & Shipping Terms:

    Minimum Order Quantity: One 40 HQ Container
    Price: negotiation
    Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed
    Payment Terms: L/C, T/T or Western Union
    Supply Ability: 3,000 Metric Tons per Month
    Contact Now
    Detailed Product Description
    Voltage Grade: 10KV Welding: According To AWS D 1.1, CO2 Welding
    Material: Hot Roll Steel Q355 Certificates: ISO9001-2008 , AAA Credit Rating, Etc
    Connection Structure: Overlap / Flange Connection Shape: Conical



    15M Hot Dip Galvanized Steel Electrical Power Pole Q345 Two Segments Overlap Type



    Product Description:



    1. Steel materials:Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65 and others equivalent steel material

    2. Welding: Welding complies with CSA and AWS, AWS D1.1 standard. No fissure, scar, overlap, layer or other defects. CO2 welding or submerged arc auto methods. If customers need any other requirements of welding, we also can make adjustment ad your request

    3. Appearance: Hot-dip galvanized in accordance with ASTM A123. The average thickness of Zinc is 86um.

    4. Pole Shape: Conical, Round, Polygonal,Tubular, Tapered

    5. Type: Suspension Pole, Tensile Pole, Strain Pole , Angle Pole, Dead-end Pole, etc

    6. Export country: Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc

    7. Quality Standard: ISO9001:2008, AAA credit rating, etc

    8. Easy install and maintenance; Short Construction Cycle; Less Land Occupation; Low Overall Cost; Weather Resistance; Anti-corrosion; Provide Professional Design by Our Experienced R&D Engineers; ODM & OEM are available



    15M Hot Dip Galvanized Steel Transmission Pole Q345 Two Segments Overlap Type



    Production Process

    • Raw material

    • Cutting

    • Bending

    • Forming operation

    • Seam welding

    • Fitting welding

    • Welding inspection(UT/RT)

    • Pre-assemble for Semi-finished products

    • Galvanization or powder coating or Bituminous painting

    • Straightening

    • Pre-assemble for finished products

    • Packing & delivery



    Product Specification:



    Products

    • 15M Hot Dip Galvanized Steel Electrical Power Pole Q345 Two Segments Overlap Type

    Application

    • Overhead Transmission Line Project

    Voltage Grade

    • 110KV

    Wind Speed

    • 160 Km/Hour . 30 m /s

    Minimum yield strength

    • 355 mpa

    Safety Factor

    • 2.0

    Life Period

    • More than 25 years, it is according to installing environment

    Once Forming

    • 16m Once forming without joint





    Material:
    we just only choose qualified & famous steel manufacturer's products to make sure our product's quality. Any material was found the defects,then all the rest materials which purchased together with it will be refused and forbidden to be receipt by the warehouse.



    Welding:
    we welding the steel poles with auto submerged-arc welding and auto welding with perfect welding line and good quality,we strickly control the test of the welding by the flaw testing with ultrasonic crack detection to make sure there is no crack,undercut,slag inclusion,hole vent for the welding.



    Hot dip galvanization:
    Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123. The hot dip galvanization technique could protect steel pole from corrosion for as long as 50 years



    15M Hot Dip Galvanized Steel Transmission Pole Q345 Two Segments Overlap Type



    Terms and Conditions:



    1. Price Term: EXW, FOB, CFR or CIF.

    The price includes pole shaft, base plate, crossarm and anchor bolt.
    Shipping seaport: Shanghai Seaport.
    Please provide drawings if you have so that we can calculate the accurate price for you.
    We also provide design according to your requests, if you don't have drawings.
    2. MOQ: One 40FT Container.

    3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.
