9M 10M Height Electric Steel Power Transmission Poles 10 KV - 220 KV Q345

Product Details:

Place of Origin:	China
Brand Name:	JSHG
Certification:	ISO/CNAS/IAF/CA
Model Number:	HG-SP-110KV

Payment & Shipping Terms:

Minimum Order Quantity:	One 40 HQ Container
Price:	negotiation
Packaging Details:	* Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time:	2 weeks per container after PO / drawing / prepayment confirmed
Payment Terms:	L/C, T/T or Western Union
Supply Ability:	3,000 Metric Tons per Month

Contact Now

Detailed Product Description

Height:	9m 10m	Shape:	Conical
Material:	Q345	Design Load:	500kg
Appearance Treatment:	Hot-dip Galvanized	Welding:	According To AWS D 1.1, CO2 Welding Or Submerged Arc Auto Methods
High Light:	transmission line pole , electrical transmission poles

Anti-corrosive 9M 10M Electric Steel Power Transmission Poles 10 KV ~ 220 KV Q345

Product Inquiry Information:

In order to design the practical poles for customers use, normally we need customer to provide us some parameter, like as following :

- Pole design load

- Top/butt diameter

- The wind Speed

- Wall thickness

- Pole type with Burial Type or Base Plate type

- The connections mode , use slip joint or flange

- Others we can further more discuss when we need.

9M 10M Height Electric Steel Power Transmission Poles 10 KV - 220 KV Q345 0

Product Description:

Products	Anti-corrosive 9M 10M Electric Steel Power Transmission Poles 10 KV ~ 220 KV Q345
Application	Electrical Power transmission and distribution line
Shape	Conical, Octagonal
Material	Applied to the material of general-purpose steel GB/T1591-2008, Q345 used in China. Q345 equipment to ASTM GR50. Min Yield Stress 345 Mpa.
Type	Direct Buried or Flange Connected
Delivery Time	2 weeks per container after PO/drawing/prepayment confirmed
Life Period	More than 25 years, it is according to installing environment
Packaging Details	Covered by Plastic Wrap or Mat or according to client's requests. The Loading Pcs of Each Container could be calculated according to client's specification and data.
Export Foreign Country	America ,Morocco,Sir Lanka ,Russia, Jordan,Guyana,Nigeria, Australia, Spain, Indonesia, Singapore, the Philippines, Kenya,etc

Product Detial:

The Low Voltage Single Circuit Electric Steel Power Pole in Hot Dip Galvanization was designed as customer's request. For transmission Line and distribution network use. We have the type with burial type or Base Plate use Anchor Bolts to Install. And exceed 12m the pole will be designed in 2 sections and connection mode use slip joint or flange. The hot dip galvanized in accordance with ASTM 123 and the zinc coating at least 86 microns.

Re material control management, all of our materials are purchased from famous mill factory to assure the quality. In addition, mill certificate issued by the mill factory with stamp and signature must be provided before unloading the material in our factory; Before putting into production, all the material must pass the chemical and physical analysis to make sure that they have met the requested strength and component.

Packaging&Shipping:

Our poles as normal are covered by Mat or straw bale at the top and bottom and woods between the poles can avoid the damage of the galvanization on the surface of steel poles, anyway also we can follow clients required.
