Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections
  • Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections
  • Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections

Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections

Place of Origin China
Brand Name JSHG
Certification ISO/CNAS/IAF/CA
Model Number HG-SP-110KV
Product Details
Tolerance:
±2%
Zinc Coating:
≥ 86 Microns
Material:
Q235, Q345, Gr.50, Gr.65
Voltage Grade:
110KV
Galvanization Standard:
ASTM A 123
Welding:
According To AWS D 1.1, CO2 Welding Or Submerged Arc Auto Methods
High Light:

transmission line pole

,

electrical transmission poles

Payment & Shipping Terms
Minimum Order Quantity
One 40 HQ Container
Price
negotiation
Packaging Details
* Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time
2 weeks per container after PO / drawing / prepayment confirmed
Payment Terms
L/C, T/T or Western Union
Supply Ability
3,000 Metric Tons per Month
Product Description




Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections



Product Description:



Products

  • Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections

Application

  • Electrical Power transmission and distribution line

Type

  • Suspension Pole, Tensile Pole, Strain Pole , Angle Pole, Dead-end Pole, etc.

Shape

  • Conical, Tubular, Tapered

Material

  • Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345 used in China.

  • Others material steel Q420, Q460 provided according to customers' request.

Wall thickness

  • 5.0mm

Marks

  • Name plate through rivet or glue, engrave as per customer
    requirement

Welding

  • Welding of substation structure complies with AWS D1.1 standard.

  • CO2 welding or submerged arc auto methods

  • No fissure, scar, overlap, layer or other defects

  • Internal and external welding makes structure more beautiful in shape

Painting

  • Bitumen painted or RAL paint

Galvanization

  • Hot dip galvanization of substation structure is in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.

Life Period

  • More than 25 years, it is according to installing environment

Standard

  • ISO 9001: 2008

Advantages

  • Short Construction Cycle

  • Low Overall Cost

  • More than 15 Years Design & Manufacture Experience

  • ODM, OEM Acceptable

  • Technical Support by E-mail



Production Process:



  • Raw material test

  • Cutting

  • Bending

  • Welding (longitudinal )

  • Dimension verify

  • Flange welding

  • Hole drilling

  • Calibration

  • Deburr

  • Galvanization or powder coating or Bituminous painting

  • Recalibration

  • Packages



Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections 0



Material Test:


1. All of our materials are purchased from famous mill factory to assure the quality with mill certificate issued by the mill factory before unloading the material in our factory;


2. Before putting into production, all the materials must pass the chemical and physical analysis to make sure that they have met the requested strength and components.







Conical Electric Power Transmission Poles 5.0mm Thickness Steel Plate Three Sections 1



The information to inquiry or purchase



  • Steel pole height and force
  • Cross arm design the position to install in the steel pole
  • Cross arm assemble
  • Safety factor
  • Wind speed
  • Type of climbing rung
  • Destination port
  • Other.





Terms and Conditions



1. Price Term: EXW, FOB, CFR or CIF.

  • The price includes pole shaft, base plate, cross arm and anchor bolt.
  • Shipping seaport: Shanghai Seaport.
  • Please provide drawings if you have so that we can calculate the accurate price for you.
  • We also provide design according to your requests, if you don't have drawings.

2. MOQ: One 40FT Container.

3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.

4. Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed.
