Q345 15m Steel Tapered Polygonal Street Light Poles Hot Dip Galvanization

Product Description:


Shape of Pole
Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc.),Tubular, Tapered
Arms
With Single / Double / Triple Outreach Arms or Brackets
 Welding
1.Welding complies with AWS D1.1 standard.
2.CO2 welding or submerged arc auto methods
3.No fissure, scar, overlap, layer or other defects
4.Internal and external welding makes the pole more beautiful in shape
5.If customers need any other requirements of welding, we also can make adjustment ad your request
 Base plate
Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.
 Surface Treatment
 Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006
Could be powder coated or painted according to clients' request
 Lamp power 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz
Torlance of the diensmtion +- 2%
 Optical assembly of lighting fixture IP 65
Electroshock resistant protective grade Grade Ⅰ
The casing anti-corrosion performance Class Ⅱ
Working atmosphere of lighting fixture -35 °C~+45 °C
Lamp power 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz
Torlance of the diensmtion +- 2%
Optical assembly of lighting fixture IP 65
Electroshock resistant protective grade Grade Ⅰ
The casing anti-corrosion performance Class Ⅱ
Working atmosphere of lighting fixture -35 °C~+45 °C
Surface treatment Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles Insert mode, innerflange mode ,face to face joint mode .
Wind Speed 160 Km/Hour
Minimum yield strength 355 mpa
Minimum ultimate tensile strength 490 mpa
Max ultimate tensile strength 620 mpa
Standard ISO 9001:2015
Length of per section Within 14m once forming without slip joint



Inquiry Detail:


If customers need our company to design the high mast light pole , following technology information are required:

1.  light pole height
2. wind design
3.safety factor
4. lamp light quantity
5.wall thickness
6. appearance requirement

Please provide drawings if you have so that we can calculate the accurate price for you.

Trade Terms:


1. Prices conditions
Price can be FOB, CIF ,EXW, which includes pole shaft, base plate, crossarm and anchor bolt.
Shipping seaport: Shanghai Seaport.
Please provide drawings if you have so that we can calculate the accurate price for you.
We also provide design according to your requests, if you don't have drawings.
2. What will be the delivery time and what will be the mode of payment?
We have large quantities in stock for normal type. Re special color and products sizes it needs 7days.
The payment can be L/C, T/T or Western Union.
3. Could you please send me the sample for the same. So that i could see and analyze its quality?
Yes. We can send samples first, samples need to be charged if the value is higher.
 4. MOQ: One 40FT Container.
 5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients’ requirement.




Quality Control Management


JSHG has passed the ISO9001 quality management system. Besides,it processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.

Meanwhile, it has formed a scientific and strict quality mangement system, which effectively and strictly guarantees the quality control of products form raw material to finished products.
