ISO 9001 Standard Commercial Light Pole Singe / Double Arm For Highway Lighting
  • ISO 9001 Standard Commercial Light Pole Singe / Double Arm For Highway Lighting
  • ISO 9001 Standard Commercial Light Pole Singe / Double Arm For Highway Lighting

ISO 9001 Standard Commercial Light Pole Singe / Double Arm For Highway Lighting

Place of Origin China
Brand Name JSHG
Certification ISO/CNAS/IAF/CA
Model Number HG-SP
Product Details
Payment Terms:
L/C, T/T, Western Union
Type:
Single / Double Arms
Appearance Treatment:
Hot Dip Galvanized With ASTM A 123, Color As Required.
Welding:
Aws D1.1,penetration Rate 100%
Connection Structure:
Overlap/flange Connection
Application:
Street / Road / Highway / Commercial Areas Lighting, Etc
Wind Speed:
160 Km/Hour
Wall Thickness:
2.3-18mm
High Light:

commercial light poles

,

parking lot light poles

Payment & Shipping Terms
Minimum Order Quantity
One 40 HQ Container
Price
negotiation
Packaging Details
* Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time
2 weeks per container after PO/drawing/prepayment confirmed
Supply Ability
3,000 Metric Tons per Month
Product Description



ISO 9001 Standard Singe / Double Arm Street Light Pole for Highway Lighting



Product Description:

Material
Normally Q235 high quality mild steel sheet. Silicon less than 2%. We have raw material checked in our lab test room after purchasing the steel sheet. We control the quality at the first beginning.
Shape of Pole
Round conical; Octagonal conical; Straight square; Tubular stepped; Polygonal
Shafts are made of steel sheet that folded into required shape and welded longitudinally by automatic arc welding machine
Brackets
Double brackets are in the shape and dimension as per customer's requirement
Welding
Welding confirms with international welding standard of CWB. No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects.
Base plate mounted
Base plate is square in shape with slotted holes for anchor bolts and dimension as per customer's requirement
Ground mounted
The length buried underground as per customer's requirement
Galvanizing
Hot dip galvanization with thickness of 80-100μm average. Inside and outside surface anti-corrosion treatment by hot dipping acid. Zinc coating is more than 85 um thick, which is in accord with GB/T13912-92 standard.



Product Specification:

Products
  • ISO 9001 Standard Singe / Double Arm Street Light Pole for Highway Lighting
Application
  • Street / road / highway / commercial areas lighting, etc
Suit for
  • Airport ,seaport, plaza, stadium ,square, highway ,street way etc
Surface Treatment
  • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006
    Can be powder coated or painted according to clients' request
Shape
  • Conoid ,Multi-pyramidal, Columniform , polygonal or conical
Min Yield Strength
  • 355 mpa
Min Ultimate Tensile Strength
  • 490 mpa
Base plate
  • Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client's requirement.
Certificates
  • ISO9001-2008 , AAA credit rating, etc



Product Advantages:

A. Management team: We have a professional design team to provide services for customers. Provide design drawings.

B. ISO 9001:2008 certificate provided .

C. QC Inspection: We have an inspector team to inspect the whole production line, and each pole should be inspected in accordance with the drawing, to make sure all poles are passed before delivery.



Application Scope:

Street light poles are widely used​ Street / Road Lighting, Highway Lighting, Commercial Areas Lighting, Seaport Lighting, AirPort Lighting, etc.

ISO 9001 Standard Commercial Light Pole Singe / Double Arm For Highway Lighting 0



Packaging&Shipping:

* Covered by Plastic Wrap or Mat or according to client's requests.
* The Loading Pcs of Each Container could be calculated according to client's specification and data.



Company Information:
ISO 9001 Standard Commercial Light Pole Singe / Double Arm For Highway Lighting 1
JIANGSU HONGGUANG STEEL POLE CO., LTD.
With over 15 Years of Experience/ Capable to Handle Volume Orders
Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.
Founded in 1998, Jiangsu Hongguang Steel Pole Co. Ltd (JSHG) specializes in manufacturing various structures. We manufacture a variety of products like structure and Substation Structure for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telcommunication poles for the telecommunication industry; Traffic Poles & Camera Poles & Sign Structures for transportation Industry and Advertising Industry.



Trade terms:

1. Price Term: EXW, FOB, CFR or CIF.
The price includes pole shaft, base plate, cross arm and anchor part.
Shipping seaport: Shanghai Seaport. For FOB, CFR or CIF price, please specify which exact model you need, and tell us your order quantity so that we can calculate the local transport charges and sea freight.
2. MOQ: 1 sets.
3. Payment: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.
4. Package: Plastic paper or according to clients requirement.
5. Delivery: for 30 sets, goods can be ready for shipment within 10 workdays after receiving deposit.
6. Parts Design Service Period: 20 years.
