40ft 800DaN Q345 Monopole Galvanised Steel Electric Pole
  • 40ft 800DaN Q345 Monopole Galvanised Steel Electric Pole

40ft 800DaN Q345 Monopole Galvanised Steel Electric Pole

Place of Origin China
Brand Name JSHG
Certification ISO/CNAS/IAF/CA
Model Number HG-SP-110KV
Product Details
Height:
40ft
Material:
Q345
Power:
10 KV ~550 KV
Thickness:
3.0mm
Design Load In Kg:
300~ 1000 Kg Appliced To 50cm From The To Pole
Type:
40ft Power Steel Pole
High Light:

Q345 Steel Electric Poles

,

Monopole galvanised steel pole

,

40ft Steel Electric Pole

Payment & Shipping Terms
Minimum Order Quantity
One 40 HQ Container
Price
negotiation
Packaging Details
* Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time
2 weeks per container after PO / drawing / prepayment confirmed
Payment Terms
L/C, T/T or Western Union
Supply Ability
3,000 Metric Tons per Month
Product Description

40ft 800DaN Q345 Material Galvanized Steel Utility Poles Electrical Power Monopole



Product Advantages:
The Hot Dip Galvanized Electrical Power Steel Tubular Pole plays an important role in electrical power transmission and distribution industry. In order to meet the increasingly higher demand for steel tubular pole, our company design and produce many kinds of steel tubular pole for the power transmission and distribution system. Besides, our electrical steel tubular pole have been tested and approved by the Transmission Pole Tower Testing Station.



As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel tubular pole could be utilize to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc. Our company has more than 15 years' design & manufacture experence which enable us to handle volume orders with high quality and low cost. In order to provide better service for customers, we promise to reply within 24 Working Hours and technical support by E-mail and calling service.



Steel Pole of National Electrification Administration (Philippines)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT, 45FT
Height
(ft)
Thickness
(mm)
Top diameter
(mm)
Butt diameter
(mm)
Design Load
(kgf)
Yield Stress
(MPa)
Zinc Coating
(micron)
25
2.5
120
152
300
345
86
30
3.0
127 226
500
345
86
35
3.0



127
248
500
345
86
40
3.0
127



317
500
345
86
45
4.0
127 328
750
345
86





Type
40ft 800 DaN Q345 Material Galvanized steel utility poles Electrical Power Monopole
Suit for
Electricity distribution
Shape
Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material
Q235 Q345 Q420
Power
10 KV ~550 KV
Design Load in Kg
300~ 1000 Kg appliced to 50cm from the to pole
Surface treatment
Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles
Insert mode,innerflange mode,face to face joint mode .
Design of pole
Against earthquake of 8 grade
Standard
ISO 9001
Welding
We has past flaw testing.Internal and external double welding makes the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness
3.0mm



Specifications:

We produce any dimensions and thicknesses straight round, tapered round, straight square, tapered square etc pole as your demand.

1) The main body pole adopts the technology of the disposable shaping

2) The welding seam is level and smooth
3) The welding of the light post is the automatic Asian arc welding
4) The antiseptic disposing of the lamp pole is the hot galvanizing and the surface is smooth and beautiful
5) Both the adjustment of the color and that of the height are alternative.
