| Place of Origin | China |
| Brand Name | JSHG |
| Certification | ISO/CNAS/IAF/CA |
| Model Number | HG-SP-110KV |
Gr65 1600dan 16kn 14m 45ft Anti Corrosive Power Steel Pole With Cross Arm
45FT distribution pole, mainly for city power grid and power distribution network. These pole belong to tubular pole, which shall be made of welded tubes, swaged and joined together. It is uniformly tapered in circular in cross-sections. The sections of the steel poles shall be designed such that the butt end of the top section fits on the top end of the second section, the butt end of the second sections fits on the top end of the third sections and so on. The varisou sections shall be fitted together by pressed frication joints. Most of power voltage as 35KV, 66KV, 69KV, 110KV, 115KV, 132KV, 220KV, after fabrication all distribution poles are delivered to the galvanizing facility to be Hot DIP Galvanized.
• Completely hot-dip galvanized after fabrication
• Fast, easy installation
• Designed for applications with stringent defection requirements
• Internal routing of transmission lines
The power pole of our company is made from quality sheets through bending, forming, automatic welding, hot dip galvanization, and powder coating. We owned an advanced production-line, which included a Flatting machine, Steel plate shearer, bending machine, Auto-closed up the machine, submerged arc welding machine, and powder coating line, and our workmanship and quality control were achieved high opinion from our clients.
Specifications:
|
Type
|
15m Electrical Power Pole
|
|||
|
Suit for
|
Electricity distribution
|
|||
|
Shape
|
Conoid ,Multi-pyramidal,Columniform,polygonal or conical
|
|||
|
Material
|
Gr65
|
|||
|
Power
|
10KV ~550KV
|
|||
|
Design Load in Kg
|
300~ 1000 Kg applied to 50cm from the to pole
|
|||
|
Surface treatment
|
Hot-dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
|
|||
|
Joint of Poles
|
Insert mode, innerflange mode, face to face joint mode.
|
|||
|
Design of pole
|
Against earthquake of 8 grade
|
|||
|
Standard
|
ISO 9001
|
|||
|
Welding
|
We has past flaw testing.Internal and external double welding makes the welding beautiful in shape
Welding Standard : AWS ( American Welding Society ) D 1.1 |
|||
|
Thickness
|
3 mm to 6 mm
|
|||
We produce any dimensions and thicknesses straight round, tapered round, straight square, tapered square etc pole as your demand.
1) The main body pole adopts the technology of the disposable shaping
2) The welding seam is level and smooth
3) The welding of the light post is the automatic Asian arc welding
4) The antiseptic disposing of the lamp pole is the hot galvanizing and the surface is smooth and beautiful
5) Both the adjustment of the color and that of the height are alternative.
