Power Line Flange Mode Q235 Electrical Power Pole
  • Power Line Flange Mode Q235 Electrical Power Pole
  • Power Line Flange Mode Q235 Electrical Power Pole

Power Line Flange Mode Q235 Electrical Power Pole

Place of Origin China
Brand Name JSHG
Certification ISO/CNAS/IAF/CA
Model Number HG-SP-110KV
Product Details
Material:
Hot Roll Steel Q235, Q345, Q420 And Others Equivalent Steel Material
Shape:
Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, Etc),Tubular, Tapered
Base Plate:
Square/round/Polygon With Slotted Holes For Anchor Bolt And Dimension As Per Client’s Requirement.
Joint:
Flange Mode
Wall Thickness:
3.5mm
Painting:
According To Clients' Request
Galvanization:
Hot Dip Galvanization Of Substation Structure Is In Accordance With Chinese Standard GB/T 13912-2002 And American Standard ASTM A123.
High Light:

Q235 steel power pole

,

Flange galvanized steel pole

Payment & Shipping Terms
Minimum Order Quantity
Negotiable
Price
negotiation
Packaging Details
* Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time
2 weeks per container after PO / drawing / prepayment confirmed
Payment Terms
L/C, T/T or Western Union
Supply Ability
3,000 Metric Tons per Month
Product Description

Power Pole Electrical Power Line Pole Galvanized Electric Power Pole For Power Line

Product Description:



Products
  • Power Pole Electrical Power Line Pole Galvanized Electric Power Pole For Power Line

Application
  • Electrical power transmission line

Standrad
  • NEA Standard

Painting
  • According to clients' request

Advantages
  • Short Construction Cycle

Galvanization
  • Hot dip galvanization of substation structure is in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
Life Period
  • More than 25 years, it is according to installing environment



Product Advantages:

The hot-dip galvanization technique could protect steel poles from corrosion for as long as 50 years.As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole could be utilized to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.





Power Line Flange Mode Q235 Electrical Power Pole 0




Manufacturing:

Raw material: Q235 or Q345 in China. We get the raw material checked in our lab test room. Silicon less than2%. We have carbon and sulfur analyzer to check the elements of the steel sheet. We'll return the steel if they are unqualified. So in this way, we can control the quality of the steel poles from the first beginning.

Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All insure us to produce steel poles with the best quality.

After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.



Product process:

All of our material are purchased from famous factory to assure the high quality.

A factory certificate issued by the factory with stamp and signature must be provided before unloading the material in our factory , otherwise we have rights to refuse.
Before put into production , all the material must be passed the chemical and physical analysis to make sure that they have met the requested strength and component.
Inspection

To assure our products qualified , we take steps as follows :

1. Management team : We have employed the experienced senior experts to take charge of the whole management ,especially the technical management and quality management .

2. Introducing ISO management :We are aware of ISO 9001:2008 certificate .

3. QC Inspection :It is our company policy that all the finished products should be inspected by our specialized QC in every manufacture step and before each shipment

Design and Detail

Lofting and designing software :We have transmission power pole designing software which can help us design all kinds of steel poles ,at the same time ,the TMA and LMA are adopted by us to design the drawing accurately

Project
We have completed many big and important projects all over the world and win the trust from our clients.
