Galvanized Steel Pole
>
|
| Place of Origin | China |
| Brand Name | JSHG |
| Certification | ISO/CNAS/IAF/CA |
| Model Number | HG-SP |
Material:
we just only choose qualified & famous steel manufacturer's products to make sure our product's quality. Any material was found the defects,then all the rest materials which purchased together with it will be refused and forbidden to be receipt by the warehouse.
Welding:
we welding the steel poles with auto submerged-arc welding and auto welding with perfect welding line and good quality,we strickly control the test of the welding by the flaw testing with ultrasonic crack detection to make sure there is no crack,undercut,slag inclusion,hole vent for the welding.
| Products |
|
| Application |
|
| Product Process |
|
| Once Forming |
|
| Advantage |
|
|
Shape |
|
|
Height (ft) |
Thickness (mm) |
Butt Diameter (mm) |
Tip Diameter (mm) |
Design Load (kg) |
Yield Stress (MPA) |
Zinc Coating (microns) |
| 25 | 2.5 | 152 | 120 | 300 | 345 | 86 |
| 30 | 3.0 | 226 | 127 | 500 | 345 | 86 |
| 35 | 3.0 | 248 | 127 | 500 | 345 | 86 |
| 40 | 3.0 | 317 | 127 | 500 | 345 | 86 |
| 45 | 3.0 | 328 | 127 | 500 | 345 | 86 |
1. Pole Shaft
2. Top Cap
3. Base Plate
4. Butt Strip Plate
5. CrossArm
6. Anchor Bolts
7. Grounding Nut & Bolts
8. Name Plate
9. Climbing Rungs
10. Template
11. Bituminous Painting if needed
