Bitumen Tapered Electrical Overhead Line Pole 35FT 3mm Thick Hot Dip Galvanized
  • Bitumen Tapered Electrical Overhead Line Pole 35FT 3mm Thick Hot Dip Galvanized
  • Bitumen Tapered Electrical Overhead Line Pole 35FT 3mm Thick Hot Dip Galvanized

Bitumen Tapered Electrical Overhead Line Pole 35FT 3mm Thick Hot Dip Galvanized

Place of Origin China
Brand Name JSHG
Certification ISO/CNAS/IAF/CA
Model Number HG-SP-110KV
Product Details
Height:
25-45ft
Shape:
8 Sides
Material:
Q345
Design Load:
500kg
Appearance Treatment:
Hot-dip Galvanized
Wall Thickness:
3.0mm
High Light:

electrical power poles

,

electrical transmission poles

Payment & Shipping Terms
Minimum Order Quantity
One 40 HQ Container
Price
negotiation
Packaging Details
* Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
Delivery Time
2 weeks per container after PO / drawing / prepayment confirmed
Payment Terms
L/C, T/T or Western Union
Supply Ability
3,000 Metric Tons per Month
Product Description




Bitumen Tapered Electrical Power Transmission Poles 35FT 3mm Thick Hot Dip Galvanized



Product Description:







National Electrification Administration (Philippines)
Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT,45FT



Height(ft)

Thickness(mm)

Butt Diameter(mm)

Top Diameter(mm)

Design Load(kg)

Yield Stress(MPA)

Zinc Coating(microns)

25

2.5

152

120

300

345

86

30

3.0

226

127

500

345

86

35

3.0

248

127

500

345

86

40

3.0

317

127

500

345

86

45 3.0 328 127 500 345 86







Technology:
 “Design and technology,professional and common, software and hardware” is JSHG‘s design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.



Welding:

Welding complies with AWS D1.1 standard. CO2 welding or submerged arc auto methods. No fissure, scar, overlap, layer or other defects. Internal and external welding makes the pole more beautiful in shape. If customers need any other requirements of welding, we also can make adjustment ad your request





Bitumen Tapered Electrical Overhead Line Pole 35FT 3mm Thick Hot Dip Galvanized 0





Packing&Delivery:
Because of there is nearly no any accessories on the poles shaft,so most of the clients agree with delivery the 25ft -45ft steel poles without package which is can save the space of the container,and also can save the purchasing cost.
Of cause,if our clients have request or standard for the package of the steel poles,we are also glad to packing the steel poles according to client's request.



Customer Service:

Reply within 24 Working Hours; Factory Direct Sale; More than 15 Years Design & Manufacture Experience; Capable to Handle Volume Orders; High-Quality and Low-Price Products; Provide Professional Design by Our Experienced R&D Engineers; Rich Exporting Experience; ODM, OEM Acceptable; Technical Support by E-mail; Calling service





Bitumen Tapered Electrical Overhead Line Pole 35FT 3mm Thick Hot Dip Galvanized 1



Quality Control Management



JSHG has passed the ISO9001 quality management system. Besides, it processes professional physical and chemical inspection lab and is equipped with X-ray detection system, ultrasonic detection system, screen display universal testing machine, photoelectric emission spectrum analyzer, as well as carbon and sulfur microcomputer analyzer etc.



Meanwhile, it has formed a scientific and strict quality management system, which effectively and strictly guarantees the quality control of products form raw material to finished products.
