Galvanized Stainless Lamp Pole Street Light Poles Single Or Double Arm

Galvanized Stainless Lamp Pole Street Light Poles Single Or Double Arm

    • Galvanized Stainless Lamp Pole Street Light Poles Single Or Double Arm
    • Galvanized Stainless Lamp Pole Street Light Poles Single Or Double Arm
  • Galvanized Stainless Lamp Pole Street Light Poles Single Or Double Arm

    Product Details:

    Place of Origin: China
    Brand Name: JSHG
    Certification: ISO/CNAS/IAF/CA
    Model Number: HG-SP

    Payment & Shipping Terms:

    Minimum Order Quantity: One 40 HQ Container
    Price: negotiation
    Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed
    Payment Terms: L/C, T/T or Western Union
    Supply Ability: 3,000 Metric Tons per Month
    Contact Now
    Detailed Product Description
    Type: Single / Double Arms Appearance Treatment: Hot Dip Galvanized With ASTM A 123, Color As Required.
    Welding: Aws D1.1,penetration Rate 100% Shape: Round / Polygonal / Conical / Tubular
    Application: Street / Road / Highway / Commercial Areas Lighting, Etc Connection Structure: Overlap/flange Connection
    Payment Terms: L/C, T/T, Western Union Material: Hot Roll Steel Q235, Q345, Q420, Q460, Gr.50, Gr.65, SS400, Etc.



    Galvanized Stainless Lamp Pole Single or Double Arm Street Light Pole



    Product Description:

    Material
    Normally Q235 high quality mild steel sheet. Silicon less than 2%. We have raw material checked in our lab test room after purchasing the steel sheet. We control the quality at the first beginning.
    Shape of Pole
    Round conical; Octagonal conical; Straight square; Tubular stepped; Polygonal
    Shafts are made of steel sheet that folded into required shape and welded longitudinally by automatic arc welding machine
    Brackets
    Double brackets are in the shape and dimension as per customer's requirement
    Welding
    Welding confirms with international welding standard of CWB. No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects.
    Base plate mounted
    Base plate is square in shape with slotted holes for anchor bolts and dimension as per customer's requirement
    Ground mounted
    The length buried underground as per customer's requirement
    Galvanizing
    Hot dip galvanization with thickness of 80-100μm average. Inside and outside surface anti-corrosion treatment by hot dipping acid. Zinc coating is more than 85 um thick, which is in accord with GB/T13912-92 standard.



    Product Specification:

    Products

    • Galvanized Stainless Lamp Pole Single or Double Arm Street Light Pole

    Application

    • Street / road / highway / commercial areas lighting, etc

    Suit for

    • Airport ,seaport, plaza, stadium ,square, highway ,street way etc

    Surface Treatment

    • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006

      Can be powder coated or painted according to clients' request

    Shape

    • Conoid ,Multi-pyramidal, Columniform , polygonal or conical

    Wall Thickness

    • 2.3~18mm

    Welding

    • Welding complies with AWS D1.1 standard.
      CO2 welding or submerged arc auto methods
      No fissure, scar, overlap, layer or other defects
      Internal and external welding makes the pole more beautiful in shape
      If customers need any other requirements of welding, we also can make adjustment ad your request

    Base plate

    • Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client's requirement.

    Life Period

    • More than 25 years, it is according to installing environment



    Product Advantages:

    1).Short Construction Cycle
    2).Less Land Occupation
    3).Low Overall Cost
    4).Easy Installation and Maintenance
    5).Weather Resistance
    6).Anti-corrosion
    7).ODM & OEM are available
    8).Capable to Handle Volume Orders
    9).Provide Professional Design by Our Experienced R&D Engineers


    Application Scope:

    Street light poles are widely used​ Street / Road Lighting, Highway Lighting, Commercial Areas Lighting, Seaport Lighting, AirPort Lighting, etc.

    Galvanized Stainless Lamp Pole Street Light Poles Single Or Double Arm



    Packaging&Shipping:

    * Covered by Plastic Wrap or Mat or according to client's requests.
    * The Loading Pcs of Each Container could be calculated according to client's specification and data.



    Company Information:
    Galvanized Stainless Lamp Pole Street Light Poles Single Or Double Arm
    JIANGSU HONGGUANG STEEL POLE CO., LTD.
    With over 15 Years of Experience/ Capable to Handle Volume Orders
    Exporting to Southeast Asia, Africa, Europe, Austrlia, the Middle East, South America, etc.
    Founded in 1998, Jiangsu Hongguang Steel Pole Co. Ltd (JSHG) specializes in manufacturing various structures. We manufacture a variety of products like structure and Substation Structure for the power transmission industry; high masts and street lighting poles for illumination, which are widely used in expressways, airports, ports and docks, depots, parking lots and stadiums; tower poles for funicular railways; Telcommunication poles for the telecommunication industry; Traffic Poles & Camera Poles & Sign Structures for transportation Industry and Advertising Industry.



    Engineering and Design Management:

    “Design and technology,professional and common, software and hardware” is JSHG‘s electric post design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.

    In the R&D Department, there are many experienced senior research & design staff and rigid development network, which ensure our design proposals meet customer demand, even exceed their expectations.
