Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line

Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line

    • Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line
    • Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line
    • Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line
    • Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line
  • Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line

    Product Details:

    Place of Origin: China
    Brand Name: JSHG
    Certification: ISO/CNAS/IAF/CA
    Model Number: HG-SP-10KV

    Payment & Shipping Terms:

    Minimum Order Quantity: One 40 HQ Container
    Price: negotiation
    Packaging Details: * Covered by Plastic Wrap or Mat or according to client's requests. * The Loading Pcs of Each Container could be calculated according to client's specification and data.
    Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed
    Payment Terms: L/C, T/T or Western Union
    Supply Ability: 3,000 Metric Tons per Month
    Contact Now
    Detailed Product Description
    Voltage Grade: 10KV Welding: According To AWS D 1.1, CO2 Welding Or Submerged Arc Auto Methods
    Shape: Round / Polygonal / Conical / Tubular / Tapered Wall Thickness: 25mm
    Base Plate: Square/round/Polygon With Slotted Holes For Anchor Bolt And Dimension As Per Client’s Requirement Type: Suspension Pole, Tensile Pole, Strain Pole , Angle Pole, Dead-end Pole, Etc



    Q345 GR65 Galvanized Steel Electric Tower Pole with 20-55FT Height for Transmission Line



    Specifications:

    Products
    • Q345 GR65 Galvanized Steel Electric Tower Pole with 20-55FT Height for Transmission Line
    Voltage
    • 10-110KV
    Shape
    • Octagonal, Dodecagonal, Hexadecagon
    Height
    • 7 ~ 30m
    Material
    • Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65 and others equivalent steel material
    Once Forming
    • 16m Once forming without joint
    Welding
    • Welding complies with AWS D1.1 standard.
    • CO2 welding or submerged arc auto methods
    • No fissure, scar, overlap, layer or other defects
    • Internal and external welding makes the pole more beautiful in shape
    • If customers need any other requirements of welding, we also can make adjustment ad your request
    Joint
    • Joint with insert mode, flange mode.
    Base plate
    • Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.
    Galvanization
    • Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
    Painting
    • According to clients' request
    Life Period
    • More than 25 years, it is according to installing environment
    Advantages
    • Anti-corrosion
    • Capable to Handle Volume Orders
    • Short Construction Cycle
    • ODM & OEM are available
    • Less Land Occupation
    • Low Overall Cost
    • Provide Professional Design by Our Experienced R&D Engineers
    • Easy Installation and Maintenance
    • Weather Resistance


    Description:

    Our electrical power pole is manufactured by the most advanced production equipments including CNC plate production line, digital controlled drill (Max working aperture is φ80mm), CNC hydraulic bending machine which adopted LVD technology from Belgium and longitudinal welding machine from Lincoln Electric Company. In terms of anti-corrosion measure, we adopt hot dip galvanization technique which ensures service life as long as 50 years. Moreover, all electrical power pole will be trail assembled before delivery which promises the smooth operation on installation site.

    The steel electrical power pole has many advantages. It can be bitumen painted according to client’s requirement which prevent the pole from corrosion. What is more, electrical power pole occupies less land and needs short construction cycle which greatly reduces construction cost, but its easy installation and maintenance shows strong practicability.



    Product Details

    Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line



    Installation Site

    Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line


    Production Process Flow Chart

    Q345 GR65 Galvanized Steel Electric Pole With 20-55FT Height For Transmission Line



    Terms and Conditions

    1. Price Term: EXW, FOB, CFR or CIF.

    The price includes pole shaft, base plate, cross arm and anchor bolt.

    Shipping seaport: Shanghai Seaport.

    Please provide drawings if you have so that we can calculate the accurate price for you.

    We also provide design according to your requests, if you don't have drawings.

    2.Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients requirement.

    3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.

    4. Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed.

    5. MOQ: One 40FT Container.


    Please feel free to contact us!







    10-500KV Hot Dip Galvanized Electrical Power Steel Tubular Pole for Power Transmission and Distribution Line.pdf
